Daechang Co., Ltd

machinery & heavy equipment031-496-3000

corrosion resistant brassModify Date : 2020-07-24 11:51:53

-Description

brass with a similar corrosion resistance to bronze, but also excellent cutting and forging.

-purpose

Widely used for indoor and outdoor building materials, contaminated water on the coast or factory sites, hot and hot water or circulating water, especially piping parts for drinking water.

-Packing

=Basic Packaging

- Less than 12 external diameter (export, less than 8 external diameter): 20~25kg nylon strap package+PP band

-External diameter Ф12 or higher (export, external diameter Ф8):PP-band

-Packing weight 1000-1500kg (export 500kg, 1000kg)

=Finishing packing

-Basic packaging + Vinyl packaging + Mastered packaging

=Tree Box Packaging

-Basic packaging + Vinyl packaging + Tree box


Chemical Composition and Mechanical Properties

Chemical composition

Alloy numberChemical composition, wt.%
KS/JISUNISCuPbFeSnZnOthers
FD(DR)seriesC4860059.0-62.01.0-2.50.20.8-1.5Rem.0.02-0.25As
MD seriesC3533059.5-64.01.5-3.5--Rem.0.02-0.25As
MB series-57.0-63.00.20.50.5Rem.0.5-3.5Bi
CZ seriesC8984483.0-86.00.20.33.0-5.07.0-10.01.0Ni,2.0-4.0Bi
0.25Sb
0.75Al,0.5-3.5Bi
0.7Al,0.02-0.25As
CB series-58.5-63.00.20.50.7Rem.
CD series-59.0-64.00.8-2.50.21.5Rem.


Mechanical Properties

Alloy numberStandard numberTemper designationDiameter and length between opposite sidesTensile strength(Mpa)Elongation(%)Hardness(HRB)
KS/JISUNIS
--------
