Scrap magnetModify Date : 2018-11-13 08:16:00
■ Scrap Magnet for SMEC Excavator
| |
Characteristic | It is a solution that drastically improves the process of sorting iron, a magnetic substance contained in household waste and construction waste. The Power POCMAG series, a hybrid scrap magnet for excavators, is available in two types. The SMEC series can be used in the process of high bucket utilization (daily waste disposal), and the SMEH series in the construction waste treatment process where the bucket utilization is relatively low. Process efficiency can be increased by 30% or more.
Maximize your productivity by dramatically reducing process losses caused by using manpower to screen iron or by repeatedly swapping electromagnets and buckets.
Customers who use electromagnets below 30% or do not require very high magnetic force can use the excavator's own power supply without the hassle of attaching an auxiliary generator. If you have any questions, please contact our sales department. |
Usage | -Iron strip removal process in recycling household waste -Iron strip removal process in incineration ash after incineration -Construction waste strip removal process |
■ Electronic Scrap Magnet for Crane
| |
Characteristic | ▼ features Use of high purity aluminum coil and excellent insulator of insulation class “H” type (NOMEX) Heat resistant coil protective material and complete waterproofing. ▼ Option RECTIFIER & CONTROL PANEL Power failure compensation system, operation panel, cable reel, radio controller
|
Usage | Strong electromagnet is attached to HOIST CRANE and is suitable for transporting scrap metal, slab, iron bars and beams. |
Specification |  |
■ Scrap Magnets for Excavators
| |
Characteristic | ▼ Features -Insulation Class “H” class excellent insulator (NOMEX) enables safe use even at high utilization rates. -The demagnetizing circuit and arc suppression circuit inside the control panel guarantee fast and reliable operation. ▼ Option Control panel -Operation S / W -Generator etc. ▼ Application Field Scrap loading dock, scrap dumping, construction / industrial waste disposal plant, shipyard, etc. Note: NOMEX is a registered trademark of Dupont, USA |
Usage | -It is effectively used for sorting magnetic materials such as iron in non-ferrous (stainless steel, brass, copper, etc.) collection facilities. -Efficient treatment of iron scrap from construction waste disposal or reconstruction sites. -It is effective for transporting steel / beams / plates / slabs / ingots in steel intermediate storage facilities or steel loading / unloading facilities. To minimize it. |
Specification | The pressure voltage (DC V) is designed to your specifications. Magnets are selected according to the customer's requirements, either round or square. In addition to the products listed in the table above, the specifications can be customized. Magnet fixed attachments are also optimized according to the attachment type of customer equipment. The main attachments are links, rotary links, and chains. |
■ Scrap Magnet for SMEH Hybrid Excavator
| |
Characteristic | ▼ Features Combined scrap magnet with excavator's shovel and powerful magnets. Over 150% more efficient than replacing excavators and scrap magnets. It is effective in removing rebar and scraps from building waste treatment plants or general waste.
▼ Option Electromagnetic Rectifier Panel, Operation S / W, Generator, etc. ▼ Application Field Scrap loading dock, scrap dumping, construction / industrial waste disposal plant, shipyard, etc. |
Usage | By attaching powerful electronic scrap magnet and excavator gourd function to the excavator, various magnetic materials mixed in soil or waste are evenly spread on a flat work site, and then easily sorted to recover the scrap. |
Specification |  |
Power tongs (for tongs)
- Designed to be easy to detach, minimize power consumption, and maximize adsorption.
- Small iron residues or residues that are difficult to handle with clippers are easy to handle and containers are easy to clean.
- Residue treatment is carried out faster than using tongs alone while minimizing working hours.
- Unlike third-party equipment, there is no terminal stand or wire around the area where the tongs are secured, so there is no abnormality or defect in securing the magnet with tongs.
- Quick coupler type electrical connectors are used to fundamentally prevent connector defects caused by arcs or potatoes in existing magnetic connectors.
