071-4111-0155
PCB ROUTER(PRS-3060A)최종 수정 일자 : 2020-08-12 09:38:43
사양
| Item | Description |
| Table Travel | X axis: 600 mm, Y axis: 300 mm, Z axis: 100 mm |
| Payload | Work (X, Y): 25Kg, Tool (Z): 15Kg |
| Maximum speed | X,Y,Z Axis : 1 ~ 1000 mm/sec |
| Repeatability accuracy | ±0.01mm for each axis |
| Resolution | X,Y, Z axis 2500 pulse/rev |
| Program language | MDI, Jog, Manual |
| Drive method | AC servo motor driving |
| Control method | PTP, ARCH, CP, SPLINE, PALLET |
| Programmable axis | 3 axis (Simultaneous control of X,Y and Z axis) |
| External interface | RS232C 1ch (Teaching pendant) RS232C 1ch (PC communication) |
| External input/output | Input : 16 points for Output : 24 points |
| Program Data memory | 32 Program (2500 Point, Shift Point 100) |
| Ambient temperature | 0℃ ~ 40℃ |
| Pneumatic Requirement | 5~7 Kg/cm2 |
| Electrical Requirement | AC 220V 50/60Hz ±10% 1KVA |
| Dimensions | Width : 800 mm, Length : 680 mm, Height : 750mm |
| Weight | 65 Kg |
| Item | Description |
| Spindle Motor | DC Brushless motor : 135 W Power X two spindles |
| Rotation speed : Min 1000 ~ Max 40000 rpm ( adjustable) | |
| Chuck diameter : Φ 3.175mm or Φ 3.0mm | |
| Router bit : Φ 0.8 mm ~ Φ 3.0 mm | |
| Cutting Speed | 1 ~ 100mm/sec |
| Material of PCB | Glass epoxy, Paper phenol, etc |
| Maximum size of PCB | Max 300mm ´ 300mm ´ 4.0mm |
| Item | Description |
| Ring Blower Motor | Motor : 1.9Kw Power |
| Dust Collector Capacity | 4.1㎥/min |
| Constant Pressure | 2500mmAg |
| Bag Filter | Polyester Teflon , 8 Pockets |
| Filter Area | 1.6㎥ |
